Chemicalworkz® Paint Analyzer – Professional paint thickness gauge

The chemicalworkz® Paint Analyzer gives you maximum control over paintwork—fast, accurate, and reliable. Whether you're inspecting a vehicle upon purchase, documenting damage during detailing, or checking the condition of a body in the workshop, this compact measuring instrument shows exactly whether and where a vehicle has been repainted , applied filler , or is still in its original condition .

Smart technology, ready to use immediately

The Paint Analyzer measures the thickness of non-metallic coatings on both magnetic (Fe) and non-magnetic (nFe) metals. The device automatically recognizes the surface type without any manual adjustments. You get instant, reliable readings on the clear, backlit LCD display .

Accurate, versatile and easy to use

• Three measurement modes : Single point measurement (SNG), continuous measurement (CTN), and differential measurement (DIF)
• Freely selectable units of measurement : μm, mil or mm
• User-friendly design : only 3 buttons, fits comfortably in your hand
• Highly sensitive sensor : detects even minimal deviations in paint thickness

The practical calibration function (zero point, offset, and 7-point calibration) allows you to perfectly adjust the device to your application. All necessary calibration foils and plates are included, so you can get started professionally right away.

What's in the box?

• chemicalworkz® Paint Analyser
• Calibration foils
• Base plates (for Fe and nFe)
• Storage bag
• Wristband
• 2x AAA batteries
• Manual

Technical specifications

• Measuring range : 0–1800 μm / 70.8 mil / 1.8 mil
• Resolution : 0.1 μm (<100 μm), 1 μm (≥100 μm)
• Accuracy : ±5 μm (≤150 μm), ±(3 % + 1 μm) (>150 μm)
• Measurement options : Single (SNG), Continuous (CTN), Difference (DIF)
• Automatic material recognition : Fe / nFe
• Display : LCD with backlight
• Power : 2× AAA batteries
• Dimensions : 121.5 × 62 × 27 mm
• Weight : 105 g
• Operating temperature : -20 °C to +40 °C
• Humidity : 10–95 % RH

Why choose the Paint Analyser from chemicalworkz?

• Detects spray, filler and irregularities in seconds
• Indispensable for vehicle inspection, detailing and bodywork
• Professional calibration options included
• Clear display, easy to operate
• Portable and reliable , even outdoors

The chemicalworkz® Paint Analyser allows you to quickly and safely detect paint defects, repairs, and hidden damage – indispensable for every car enthusiast, detailer, professional, or damage expert.
